ProDrive-40W-24DC
ProDrive Series, 40W, 24VDC 5 in 1 Low Profile Dimmable LED Driver
DESCRIPTION
The EnoLED 5-in-1 Dimming Driver is a professional-grade, low-profile solution built for cabinet integration, millwork, and task lighting. Supporting TRIAC, ELV, 0-10V, 1-10V, and PWM protocols, it delivers smooth, flicker-free dimming down to 0.1%. Its compact form makes it ideal for tight architectural spaces, while the cost-effective, ETL Class 2 design ensures reliable performance for high-volume installations.
FEATURES
- 5-in-1 dimming supports TRIAC, ELV, 0-10V, 1-10V, and PWM
- Soft dimming down to 0.1% for smooth flicker-free performance
- Low profile design makes it ideal for tight-space installations
- Universal input voltage range of 120–277VAC
- Class 2 certified and ETL-listed for low-voltage systems
- High efficiency with up to 92% performance
- Compliant with Title 24 Part 6 flicker requirements
- Backed by a 6-year warranty for long-term reliability
| Max Power | 40W |
| Input Voltage | 120-277VAC |
| Output Voltage | 24VDC |
| Dimmable | TRIAC / MLV / ELV / 0-10V 1-10V / Potentiometer 10V PWM |
| IP Rating | IP21 |
| Efficiency @ Full Load | 92% |
| Warranty | 6 Year |
| Dimensions (W x H x L) | 2.28” x 0.78” x 6.29” |
Ordering Information
| Ordering Code | Input Voltage | Output Voltage | Max Load | Class 2 | Dimmable | Environment | Dimensions |
|---|---|---|---|---|---|---|---|
ProDrive-40W-24DC |
120-277VAC |
24VDC |
40W |
Yes |
TRIAC / MLV / ELV / 0-10V
1-10V / Potentiometer 10V PWM |
IP21 |
2.28” x 0.78” x 6.29” |
ProDrive-60W-24DC |
120-277VAC |
24VDC |
60W |
Yes |
TRIAC / MLV / ELV / 0-10V
1-10V / Potentiometer 10V PWM |
IP21 |
2.5” x 0.86” x 7.28” |
ProDrive-96W-24DC |
120-277VAC |
24VDC |
96W |
Yes |
TRIAC / MLV / ELV / 0-10V
1-10V / Potentiometer 10V PWM |
IP21 |
2.5” x 0.86” x 7.28” |
