XRD-96W-24VDC
XRD Series , 96W, 24VDC Phase Cut Dimmable LED Driver
DESCRIPTION
The XRD Series is the most compact dimmable LED driver with a built-in junction box—ideal for tight spaces and modern installations.
Fully compatible with TRIAC, MLV, and ELV (leading/trailing edge) dimmer switches.
Seamlessly powers LED tapes, including COB, with no minimum load required.
Delivers flicker-free dimming to 1%, supports full load with no derating, and operates at 89% efficiency.
UL Class 2 certified with auto-reset protection—perfect for residential, commercial, and architectural projects.
FEATURES
- Most compact dimmable junction box driver on the market
- Dimmable with TRIAC, MLV, or ELV dimmers (leading or trailing edge)
- Compatible with forward-phase and box loads
- Works seamlessly with COB tape lights
- Flicker-free dimming down to 1%
- No minimum load required
- Full load capable – no derating needed
- 89% efficiency at full load
- UL Listed – Class 2 compliant
| Max Power | 96W |
| Input Voltage | 120VAC |
| Output Voltage | 24VDC |
| Dimmable | Triac / ELV (leading or trailing edge) |
| IP Rating | IP23 |
| Efficiency @ Full Load | 88% |
| Warranty | 6 Year |
| Dimensions (W x H x L) | 1.85” x 1.35” x 6.20” |
Ordering Information
| Ordering Code | Input Voltage | Output Voltage | Max Load | Class 2 | Dimmable | Environment | Dimensions |
|---|---|---|---|---|---|---|---|
XRD-40W-24VDC |
120VAC |
24VDC |
40W |
Yes |
Incandescent, CFL / LED, MLV, ELV |
IP21 |
6.20″ x 1.85″ x 1.35″ |
XRD-60W-24VDC |
120VAC |
24VDC |
60W |
Yes |
Incandescent, CFL / LED, MLV, ELV |
IP21 |
6.20″ x 1.85″ x 1.35″ |
XRD-75W-24VDC |
120VAC |
24VDC |
75W |
Yes |
Incandescent, CFL / LED, MLV, ELV |
IP21 |
6.20″ x 1.85″ x 1.35″ |
XRD-96W-24VDC |
120VAC |
24VDC |
96W |
Yes |
Incandescent, CFL / LED, MLV, ELV |
IP21 |
6.20″ x 1.85″ x 1.35″ |
XRD-40W-12VDC |
120VAC |
12VDC |
40W |
Yes |
Incandescent, CFL / LED, MLV, ELV |
IP21 |
6.20″ x 1.85″ x 1.35″ |
XRD-60W-12VDC |
120VAC |
12VDC |
60W |
Yes |
Incandescent, CFL / LED, MLV, ELV |
IP21 |
6.20″ x 1.85″ x 1.35″ |
