UniBasic-35

UniBasic-35

3500K • 329lm/ft • 3W/ft COB LED Tape Light

DESCRIPTION

The UniBasic COB Dotless LED Tape offers uniform illumination, ideal for low-clearance areas and reflective surfaces, featuring 90+ CRI and up to 347 lumens per foot. It provides various dimming options, including Incandescent, CFL, LED, MLV, ELV, 0-10V, and wireless control. UL Listed Class 2 certified, each roll includes a 36” lead wire and tape connector for smooth installation. Easily cut every 1.97” (50 mm) and install with the reliable Red 3M VHB adhesive backing. Available in 16ft and 100ft reels.

FEATURES

Product lineUniBasic
Input Voltage24VDC
CRI90+
Power3W/ft
Lumens329lm/ft
Cut Length1.97”
EnvironmentIP20
Dimensions (W x H)0.39” x 0.05”
Maximum Run25ft (from power feed)
Dimming Options• Incandescent • CFL/LED • MLV • ELV • 0-10V • Dimmer switch / wireless app & wall switch.

Ordering Information​

Ordering Code Length Voltage CCT CRI Wattage Lumens Cuttable IP Rating
UniBasic-27-16
16.4ft
24VDC
2700K
90+
3W/ft
293lm/ft
1.97”
IP20
UniBasic-30-16
16.4ft
24VDC
3000K
90+
3W/ft
314lm/ft
1.97”
IP20
UniBasic-35-16
16.4ft
24VDC
3500K
90+
3W/ft
329lm/ft
1.97”
IP20
UniBasic-40-16
16.4ft
24VDC
4000K
90+
3W/ft
347lm/ft
1.97”
IP20
UniBasic-50-16
16.4ft
24VDC
5000k
90+
3W/ft
345lm/ft
1.97”
IP20
UniBasic-27-100
100ft
24VDC
2700K
90+
3W/ft
293lm/ft
1.97″
IP20
UniBasic-30-100
100ft
24VDC
3000K
90+
3W/ft
314lm/ft
1.97″
IP20
UniBasic-35-100
100ft
24VDC
3500K
90+
3W/ft
329lm/ft
1.97″
IP20
UniBasic-40-100
100ft
24VDC
4000K
90+
3W/ft
347lm/ft
1.97″
IP20
UniBasic-50-100
100ft
24VDC
5000K
90+
3W/ft
345lm/ft
1.97″
IP20
